Low Pressure Ball Valves

Materials: • Body: forged nickel-plated brass • Ball: chromed brass • Ball seal: PTFE
Hydraulics Ball & Gate Valves
BSP
  • Technical specs
Part number Variation name Outside diameter in millimetres Bend radius in millimetres Burst pressure in bar Maximum gauge pressure in bar Burst pressure Vacuum level in inches of mercury Thread size Thread size in millimetres Thread size in UNF Size of inlet thread Size of outlet thread To suit internal diameter of hose To suit metric internal diameter of hose To suit metric outside Flange size Seal Type Working temp Output Signal mA Litres per Minute Mpa Working pressure Micron Rating for filtration To Suit Notes Length MM Hole Centres in mm Height in MM Port Size Oem Code Element Media Old Ref Material Model Box QTY Bypass in PSIG Float Material Flow rate in cubic Litres per second ElemnentSize Voltage Max Litres per Minute Wattage OD In INCHES Max working pressure Size Max Pressure for rotation Displacement cm4412 Volume Function To suit Cartridge Ratio No. of Stations Type Frame Size Group Number
LPBV-04 BSP 50 1/4”
LPBV-04MF Male x Female, BSP 50 1/4”
LPBV-04NPT NPT 50 1/4”
LPBV-06 BSP 50 3/8”
LPBV-06MF Male x Female, BSP 50 3/8”
LPBV-06NPT NPT 50 3/8”
LPBV-08 BSP 50 1/2”
LPBV-08MF Male x Female, BSP 50 1/2”
LPBV-08NPT NPT 50 1/2”
LPBV-12 BSP 40 3/4”
LPBV-12MF Male x Female, BSP 40 3/4”
LPBV-12NPT NPT 40 3/4”
LPBV-16 BSP 40 1”
LPBV-16MF Male x Female, BSP 40 1”
LPBV-16NPT NPT 40 1”
LPBV-20 BSP 30 1.1/4”
LPBV-20MF Male x Female, BSP 30 1.1/4”
LPBV-20NPT NPT 30 1.1/4”
LPBV-24 BSP 30 1.1/2”
LPBV-24MF Male x Female, BSP 30 1.1/2”
LPBV-24NPT NPT 30 1.1/2”
LPBV-32 BSP 25 2”
LPBV-32MF Male x Female, BSP 25 2”
LPBV-32NPT NPT 25 2”
LPBV-40 BSP 18 2.1/2”
LPBV-40NPT NPT 18 2.1/2”
LPBV-48 BSP 16 3”
LPBV-48NPT NPT 16 3”
LPBV-64 BSP 14 4”
LPBV-64NPT NPT 14 4”
