Superflexible Medium Duty Suction Hose
Your item(s) have been added to your shopping basket
Superflexible Medium Duty Suction Hose
- Technical specs
| Part number | Variation name | Inside diameter | Wall thickness in mm | Max gauge pressure in bar | Bend radius in mm |
|---|---|---|---|---|---|
| SFMDS1-10 | Dark Olive Green, 10 Metre Coils | 1" | 3.5 | 8 | 110 |
| SFMDS1-30 | Dark Olive Green, 30 Metre Coils | 1" | 3.5 | 8 | 110 |
| SFMDS112-10 | Dark Olive Green, 10 Metre Coils | 1.1/2" | 4 | 7 | 150 |
| SFMDS112-30 | Dark Olive Green, 30 Metre Coils | 1.1/2" | 4 | 7 | 150 |
| SFMDS114-10 | Dark Olive Green, 10 Metre Coils | 1.1/4" | 3.7 | 7 | 135 |
| SFMDS114-30 | Dark Olive Green, 30 Metre Coils | 1.1/4" | 3.7 | 7 | 135 |
| SFMDS2-10 | Dark Olive Green, 10 Metre Coils | 2" | 4.3 | 6.5 | 200 |
| SFMDS2-30 | Dark Olive Green, 30 Metre Coils | 2" | 4.3 | 6.5 | 200 |
| SFMDS212-10 | Dark Olive Green, 10 Metre Coils | 2.1/2" | 5.2 | 7 | 250 |
| SFMDS212-30 | Dark Olive Green, 30 Metre Coils | 2.1/2" | 5.2 | 7 | 250 |
| SFMDS3-10 | Dark Olive Green, 10 Metre Coils | 3" | 5 | 4.5 | 300 |
| SFMDS3-30 | Dark Olive Green, 30 Metre Coils | 3" | 5 | 4.5 | 300 |
| SFMDS312-10 | Dark Olive Green, 10 Metre Coils | 3.1/2" | 5.5 | 5 | 350 |
| SFMDS312-30 | Dark Olive Green, 30 Metre Coils | 3.1/2" | 5.5 | 5 | 350 |
| SFMDS34-10 | Dark Olive Green, 10 Metre Coils | 3/4" | 3.3 | 8 | 100 |
| SFMDS34-30 | Dark Olive Green, 30 Metre Coils | 3/4" | 3.3 | 8 | 100 |
| SFMDS4-10 | Dark Olive Green, 10 Metre Coils | 4" | 6 | 5 | 400 |
| SFMDS4-30 | Dark Olive Green, 30 Metre Coils | 4" | 6 | 5 | 400 |
| SFMDS6-10 | Dark Olive Green, 10 Metre Coils | 6" | 7.5 | 2 | 600 |
| SFMDS6-30 | Dark Olive Green, 30 Metre Coils | 6" | 7.5 | 2 | 600 |
