Nylon 12 Recoil Air Hose, 90° Tails
Your item(s) have been added to your shopping basket
Nylon 12 Recoil Air Hose, 90° Tails
- Technical specs
| Part number | Variation name | Inside diameter | Inside diameter mm | Outside diameter | Outside diameter in mm | Working length in feet | Working length in metres | Thread size |
|---|---|---|---|---|---|---|---|---|
| NRH12-12B | Blue, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 12 | 3.6 | 3/8" |
| NRH12-12R | Red, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 12 | 3.6 | 3/8" |
| NRH12-12Y | Yellow, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 12 | 3.6 | 3/8" |
| NRH12-25B | Blue, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 25 | 7.6 | 3/8" |
| NRH12-25R | Red, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 25 | 7.6 | 3/8" |
| NRH12-25Y | Yellow, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 25 | 7.6 | 3/8" |
| NRH12-40B | Blue, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 40 | 12.2 | 3/8" |
| NRH12-40R | Red, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 40 | 12.2 | 3/8" |
| NRH12-40Y | Yellow, Brass Nickel Plated Swivel, BSPT | 3/8" | 10 | 1/2" | 13 | 40 | 12.2 | 3/8" |
| NRH38-12B | Blue, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 12 | 3.6 | 1/4" |
| NRH38-12R | Red, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 12 | 3.6 | 1/4" |
| NRH38-12Y | Yellow, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 12 | 3.6 | 1/4" |
| NRH38-25B | Blue, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 25 | 7.6 | 1/4" |
| NRH38-25R | Red, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 25 | 7.6 | 1/4" |
| NRH38-25Y | Yellow, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 25 | 7.6 | 1/4" |
| NRH38-40B | Blue, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 40 | 12.2 | 1/4" |
| NRH38-40R | Red, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 40 | 12.2 | 1/4" |
| NRH38-40Y | Yellow, Brass Nickel Plated Swivel, BSPT | 5/16" | 8 | 3/8" | 10 | 40 | 12.2 | 1/4" |
| NRH516-12B | Blue, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 12 | 3.6 | 1/4" |
| NRH516-12R | Red, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 12 | 3.6 | 1/4" |
| NRH516-12Y | Yellow, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 12 | 3.6 | 1/4" |
| NRH516-25B | Blue, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 25 | 7.6 | 1/4" |
| NRH516-25R | Red, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 25 | 7.6 | 1/4" |
| NRH516-25Y | Yellow, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 25 | 7.6 | 1/4" |
| NRH516-40B | Blue, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 40 | 12.2 | 1/4" |
| NRH516-40R | Red, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 40 | 12.2 | 1/4" |
| NRH516-40Y | Yellow, Brass Nickel Plated Swivel, BSPT | 1/4" | 6 | 5/16" | 8 | 40 | 12.2 | 1/4" |
