PVC Ducting

Hose, Tubing & Couplings Industrial Hose & PVC Ducting
Light Duty, 10 Metre Coils
  • Technical specs
Part number Variation name Inside diameter mm Max gauge pressure in bar Bend radius in mm
LDPVC102-10 Light Duty, 10 Metre Coils 102 0.05 50
LDPVC115-10 Light Duty, 10 Metre Coils 115 0.04 58
LDPVC127-10 Light Duty, 10 Metre Coils 127 0.04 64
LDPVC152-10 Light Duty, 10 Metre Coils 152 0.03 76
LDPVC25-10 Light Duty, 10 Metre Coils 25 0.14 13
LDPVC32-10 Light Duty, 10 Metre Coils 32 0.14 16
LDPVC38-10 Light Duty, 10 Metre Coils 38 0.13 20
LDPVC45-10 Light Duty, 10 Metre Coils 45 0.11 23
LDPVC51-10 Light Duty, 10 Metre Coils 51 0.11 26
LDPVC57-10 Light Duty, 10 Metre Coils 57 0.11 28
LDPVC63-10 Light Duty, 10 Metre Coils 63 0.09 32
LDPVC76-10 Light Duty, 10 Metre Coils 76 0.08 38
LDPVC80-10 Light Duty, 10 Metre Coils 80 0.08 38
LDPVC89-10 Light Duty, 10 Metre Coils 89 0.06 45
MDPVC102-10 Medium Duty, 10 Metre Coils 102 0.4 102
MDPVC115-10 Medium Duty, 10 Metre Coils 115 0.4 145
MDPVC127-10 Medium Duty, 10 Metre Coils 127 0.4 175
MDPVC152-10 Medium Duty, 10 Metre Coils 152 0.2 190
MDPVC32-10 Medium Duty, 10 Metre Coils 32 0.5 32
MDPVC38-10 Medium Duty, 10 Metre Coils 38 0.5 38
MDPVC45-10 Medium Duty, 10 Metre Coils 45 0.5 45
MDPVC51-10 Medium Duty, 10 Metre Coils 51 0.4 50
MDPVC57-10 Medium Duty, 10 Metre Coils 57 0.4 50
MDPVC63-10 Medium Duty, 10 Metre Coils 63 0.4 65
MDPVC76-10 Medium Duty, 10 Metre Coils 76 0.4 75
MDPVC80-10 Medium Duty, 10 Metre Coils 80 0.4 80
MDPVC89-10 Medium Duty, 10 Metre Coils 89 0.4 90
